CNC Automatic Sheet Metal Punching Motor Machine for Stainless Steel and Carbon Steel Processing
| MOQ: | 1 set |
| Price: | Negotiable |
| Standard Packaging: | Wooden case |
| Delivery Period: | 60 days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 200 sets/year |
CNC Automatic Sheet Metal Punching Motor Machine for Stainless Steel and Carbon Steel Processing
Product Introduction:
The CNC plate punching machine is employed for punching, marking, and drilling steel plates in the construction of steel towers. Furthermore, it is also used for punching, drilling, and marking metal plates across a variety of other industries.
Product specification:
| Model | BNHD120 | |
| Max size of work piece (mm) | 1500*800 | |
| Max. punching diameter (mm) | Φ26 | |
| Max. drilling diameter (mm) | Φ50 | |
| Taper of drilling spindle | BT50 | |
| Plate thickness (mm) | Punching | 5～25 (Q235) |
| Drilling | 40 | |
| Punching force (kN) | 1000/1200 | |
| Marking force (kN) | 800/1200 | |
| Min. distance between hole and plate edge (mm) | Punching | 25 |
| Drilling | Depends on hole diameter | |
| Character size(mm) | 14*10*19 | |
| Qty. of character | 12 | |
| Die-stations | 4 | |
| Feeding speed of drilling (mm/min) | 0~5000 | |
| Stroke of drilling spindle(mm) | 350 | |
| Rotation speed of drilling spindle(r/min) | 30~3000 | |
| Programming mode | Command programming, Auto CAD drawing or layout software | |
| Overall dimensions L*W*H (m) | 3.3*3.2*3 | |
Product Features:
1. The frame of the plate marking machine is constructed using a C-type welded plate design, ensuring superior rigidity and providing an expansive handling area. The machine is equipped with three die stations, one of which is specifically dedicated to marking, and features automatic die station switching. The clamping system is versatile, accommodating various workpieces, with a zero baffle serving as the reference point, and the workpiece supported by a rolling-ball work table. The movement of the X and Y axes is driven by servo motors and ball screws, while the PLC controls the punching position, allowing for full automation of the machining process. The operator inputs the workpiece program, enabling repeated use.
2. The steel plate punching machine employs CNC technology and servo motor-driven feeding, ensuring high efficiency and consistent precision of the workpieces.
3. The key functional components are designed with a modular assembly, enabling easy maintenance and repair.
4. Perform punching, marking, and drilling operations on a single plate.
5. The drilling unit features functions such as rapid descent, slow work-feed, and fast return feeding, all designed to enhance operational efficiency.
6. Simple programming allows for the input of hole diameter, position, and workpiece quantity into the computer. Additionally, it supports programs generated by lofting software or direct CAD/CAM conversion.
7. Equipped with a self-diagnosis function for fault detection.
This CNC plate punching machine is a specialized metalworking system expertly engineered to perform punching, marking, and drilling operations on steel plates used in the steel tower manufacturing industry. It ensures outstanding machining precision, adhering to rigorous tolerance standards and surface finish requirements. Beyond its primary application in the steel tower sector, this versatile machine offers reliable punching, drilling, and marking capabilities for metal plates across a wide range of industrial fields. It consistently provides high operational efficiency and accuracy for various metal workpieces, optimizing workflows and enhancing product quality across multiple industrial applications.
