Industrial High-Speed CNC H Beam Drilling Machine With Three Independent Spindles
Product Introduction:
The CNC 3D Drilling Machine is designed with three independent drilling modules, consisting of vertical, left-side, and right-side spindle units. Each spindle assembly is controlled by two CNC axes and a digitally managed hydraulic feed mechanism operating in the direction perpendicular to the workpiece surface. The drilling tools are installed using quick-release tool holders, enabling fast and precise tool replacement. Each spindle operates independently, allowing simultaneous multi-angle drilling operations. After the workpiece is automatically clamped, the complete hole pattern can be processed in a single machining cycle, significantly enhancing production efficiency, machining accuracy, and overall processing consistency.
Product Parameters:
| Model | BHD1000/3 |
| H Beam width range (mm) | 100~1000 |
| H Beam height range (mm) | 100~500 |
| Channel steel width range (mm) | 100~1000 |
| Channel steel height range (mm) | 100~250 |
| Max. workpiece thickness (mm) | 80 |
| Max. workpiece length (m) | 12 or 15 (optional) |
| Drilling spindle qty. | Total 3 spindles, one spindle on the upper unit, left side and right side respectively |
| Spindle hole taper | BT40 |
| Max.drilling diameter (mm) | 40 |
| Spindle motor power (kW) | 11/15 |
| Spindle speed (r/min) | 100~3000 |
| Spindle feeding speed (m/min) | 0~10 |
| X-axis feeding speed (m/min) | 0~20 |
| Qty of tool magazine | 3 |
| Tool magazine type and capacity | Row type, 3x4 (optional) |
| Marking unit (optional) | Disc typing, 36 characters, character size Φ10mm |
| CNC system | German, Japan, China INVT |
| Cooling method | Spray cooling, internal cooling + external cooling |
| Machine Overall Size (m) | About 33x5.5x3.5 |
| Total Power(kW) | About 60 |
| The above parameters can be adjusted and changed according to customer's specific requirements. | |
Product Features:
1. The machine integrates three individually controlled drilling units, enabling simultaneous machining from multiple directions. Each drilling module is equipped with a dedicated high-precision spindle head, delivering high drilling efficiency, exceptional hole positioning accuracy, and stable machining quality throughout continuous production.
2. Manual entry of workpiece thickness and tool length is no longer required. Through an advanced intelligent detection system, the equipment automatically identifies machining conditions and adjusts feed speed and drilling parameters accordingly, ensuring optimized processing efficiency, reliable operation, and consistent machining performance.
3. The machine structure is manufactured from heavy-duty welded steel plates reinforced with square-section structural members. After undergoing comprehensive stress-relief treatment, the robust frame design, combined with roller-guided spindle support mechanisms, provides outstanding rigidity, excellent vibration resistance, and superior long-term dimensional stability for precision machining applications.
4. The CNC control system supports automatic loading, recognition, and conversion of engineering drawings generated by AutoCAD and various steel structure detailing software. Compatible with DXF, NC1, and other commonly used industrial data formats, the system enables seamless connection with existing digital design and intelligent manufacturing workflows.
5. A centralized automatic lubrication system and an independent air-conditioning system for the electrical control cabinet are included as standard configurations. These features maintain stable operating conditions, minimize mechanical wear, improve component reliability, and extend the overall service life of the equipment.
6. The machine is equipped with a fully automated material handling system capable of automatic workpiece clamping, positioning, and feeding. This intelligent automation reduces manual intervention, increases production efficiency, and lowers operator workload during continuous machining operations.
7. The CNC control platform is based on a PLC system operating within a Windows environment and features an advanced Human–Machine Interface (HMI). With high-speed data processing, graphical machining simulation, and real-time production monitoring functions, the system simplifies machine operation, program management, and production supervision.
8. Each drilling spindle is powered by a high-performance drive motor supplied by internationally reputable manufacturers, ensuring reliable operation, powerful machining capability, and consistently excellent drilling performance.
9. All major mechanical, hydraulic, pneumatic, and electrical components are selected from globally recognized suppliers, providing superior equipment reliability, extended component durability, reduced maintenance requirements, and stable long-term operating performance.
The representative workpieces processed by the CNC H-Beam Drilling, Marking, and Shearing Machine include standard H-beam sections with various flange widths and web thicknesses, along with channel steel specimens of different dimensions. These demonstration samples effectively illustrate the machine’s capability to achieve precise hole positioning, high-quality thread machining, and clear, accurate marking results. They provide customers, engineers, and quality inspection personnel with a reliable reference for evaluating machining precision, process stability, and equipment performance under practical production conditions.
The High-Speed CNC H-Beam Drilling, Marking, and Shearing Machine is extensively employed in structural steel fabrication, bridge construction, and other heavy steel manufacturing industries. In steel fabrication workshops, it performs high-accuracy drilling, marking, and shearing of H-beams used in structural frameworks, support systems, and load-bearing assemblies, ensuring precise fabrication and efficient installation. For bridge engineering applications, the equipment provides accurate machining of H-beam components, improving joint precision, structural integrity, and long-term load-bearing capability. Combining high productivity, exceptional machining accuracy, and reliable operational performance, the machine delivers an advanced manufacturing solution for large-scale infrastructure projects while enhancing production efficiency, product quality, and overall project execution.
